Specifications

Ultrix’ hardware is designed to guaranty the highest level of resilience and stability using the best available components.

Ultrix Hardware Specifications 1RU 2RU 5RU 12RU
PHYSICAL DIMENSIONS
Width 17.5 inches 17.5 inches 17.5 inches 17.5 inches
Depth 7.9 inches 7.9 inches 7.9 inches 7.9 inches
Height 1.74 inches 3.48 inches 8.7 inches 21 inches
Frame Weight (approx) 4.06 kg (9 lbs) 5.44 kg (12lbs) 6.35 kg (14 lbs) 34.47 kg (76 lbs)
I/O Card Weight (approx per board) 1.36 kg (3 lbs) 1.36 kg (3 lbs) 1.36 kg (3 lbs) 1.36 kg (3 lbs)
Video Matrix Size (max) 36×36 72×72 160×160 288×288
Default I/O Slots 1 (16×16 HD BNC + 2AUX I/O Ports) 1 (16×16 HD BNC + 2AUX I/O Ports) None None
Optional I/O Slots using ULTRIX-HDX-IO 1 (16×16 HD BNC + 2AUX I/O Ports) 3 (16×16 HD BNC + 2AUX I/O Ports) 9 (16×16 HD BNC + 2AUX I/O Ports) slots 1-8; FLEX slot 16×16 HD BNC only 16 (16×16 HD BNC + 2AUX I/O Ports)
Optional I/O Slots using ULTRIX-IP-IO 1 (x4 25G SFP28 + 2 SFP I/O Ports) 3 (x4 25G SFP28 + 2 SFP I/O Ports) 9 (x4 25G SFP28 + 2 SFP I/O Ports) 16 (x4 25G SFP28 + 2 SFP I/O Ports)
Optional I/O Slots using ULTRIX-SFP-IO 1 (16 SFP ports + 2AUX I/O Ports) 3 (16 SFP ports + 2AUX I/O Ports) 9 (16 SFP ports + 2AUX I/O Ports) slots 1-8; FLEX slot 16 SFP ports only 16 (16 SFP ports + 2AUX I/O Ports)
Ultriscape MV Head License per Slot 3 SDI or 2 IP 3 SDI or 2 IP 3 SDI or 2 IP 3 SDI or 2 IP
Maximum Ultriscape MV heads per System 6 SDI or 2 IP 12 SDI or 6 IP 27 SDI or 18 IP 48 SDI or 32 IP
OTHER
PSU 1 external brick 2 external bricks 1RU external frame (x2) 1RU external frame
Optional Redundant PSU (additional) 1 external brick 2 external bricks 1 ULTRIPOWER-PS 2 ULTRIPOWER-PS
Ultripower support Optional Optional Standard Standard
Fan Module 1 2 5 10
INPUT SPECIFICATION-ULTRIX-HDX-IO
Standard Input HD BNC HD BNC HD BNC HD BNC
Signal Type SDI Formats: 270 Mb/s, 1.5 Gb/s, 3.0 Gb/s, 12 Gb/s SDI Formats: 270 Mb/s, 1.5 Gb/s, 3.0 Gb/s, 12 Gb/s SDI Formats: 270 Mb/s, 1.5 Gb/s, 3.0 Gb/s, 12 Gb/s SDI Formats: 270 Mb/s, 1.5 Gb/s, 3.0 Gb/s, 12 Gb/s
Impedance 75 Ohm 75 Ohm 75 Ohm 75 Ohm
Max Input Level 800mV 800mV 800mV 800mV
Return Loss Per SMPTE 2082-1 Per SMPTE 2082-1 Per SMPTE 2082-1 Per SMPTE 2082-1
Typical Equalization UHD 60M, 3G 180M, HD 200M, SD 400M UHD 60M, 3G 180M, HD 200M, SD 400M UHD 60M, 3G 180M, HD 200M, SD 400M UHD 60M, 3G 180M, HD 200M, SD 400M
SFP Aux Connector optional optional optional optional
OUTPUT SPECIFICATION-ULTRIX-HDX-IO
Standard Output HD BNC HD BNC HD BNC HD BNC
MV outputs 1.5 Gb/s or 3.0 Gb/s 1.5 Gb/s or 3.0 Gb/s 1.5 Gb/s or 3.0 Gb/s 1.5 Gb/s or 3.0 Gb/s
Impedance 75 Ohm 75 Ohm 75 Ohm 75 Ohm
Amplitude 800mV +/- 10% 800mV +/- 10% 800mV +/- 10% 800mV +/- 10%
Rise & Fall Time 270Mb/s: 400-800ps, 1.5 & 3Gb/s: <135ps, 12Gb/s: <45ps 270Mb/s: 400-800ps, 1.5 & 3Gb/s: <135ps, 12Gb/s: <45ps 270Mb/s: 400-800ps, 1.5 & 3Gb/s: <135ps, 12Gb/s: <45ps 270Mb/s: 400-800ps, 1.5 & 3Gb/s: <135ps, 12Gb/s: <45ps
DC Offset 0.0V +/- 10% 0.0V +/- 10% 0.0V +/- 10% 0.0V +/- 10%
Overshoot < 10% < 10% < 10% < 10%
Jitter <0.2 UI Alignment (up to 3G), <0.3 UI Alignment (12G), <2UI Timing (up to 270M), <1UI Timing (1.5G), <2UI Timing (3G, 12G) <0.2 UI Alignment (up to 3G), <0.3 UI Alignment (12G), <2UI Timing (up to 270M), <1UI Timing (1.5G), <2UI Timing (3G, 12G) <0.2 UI Alignment (up to 3G), <0.3 UI Alignment (12G), <2UI Timing (up to 270M), <1UI Timing (1.5G), <2UI Timing (3G, 12G) <0.2 UI Alignment (up to 3G), <0.3 UI Alignment (12G), <2UI Timing (up to 270M), <1UI Timing (1.5G), <2UI Timing (3G, 12G)
Return Loss Per SMPTE 2082-1 Per SMPTE 2082-1 Per SMPTE 2082-1 Per SMPTE 2082-1
SFP Aux Connector optional optional optional optional
CARD SPECIFICATION-ULTRIX-IP-IO
Standard Interface (4) 25GE SFP28 (4) 25GE SFP28 (4) 25GE SFP28 (4) 25GE SFP28
Video Streams per Card UHD: 4+4 redundant, 8 non-redundant, 6G: 4+4 redundant, 8 non-redundant, 3G/HD: 16+16 redundant, 16 non-redundant UHD: 4+4 redundant, 8 non-redundant, 6G: 4+4 redundant, 8 non-redundant, 3G/HD: 16+16 redundant, 16 non-redundant UHD: 4+4 redundant, 8 non-redundant, 6G: 4+4 redundant, 8 non-redundant, 3G/HD: 16+16 redundant, 16 non-redundant UHD: 4+4 redundant, 8 non-redundant, 6G: 4+4 redundant, 8 non-redundant, 3G/HD: 16+16 redundant, 16 non-redundant
Video Format Support • 720p 25/ 29.97/ 30/ 50 / 59.94 / 60
• 1080i 50 / 59.94 / 60
• 1080p 25/ 29.97/ 30/ 50 / 59.94 / 60
• 2160p 25/ 29.97/ 30/ 50 / 59.94/60
• 720p 25/ 29.97/ 30/ 50 / 59.94 / 60
• 1080i 50 / 59.94 / 60
• 1080p 25/ 29.97/ 30/ 50 / 59.94 / 60
• 2160p 25/ 29.97/ 30/ 50 / 59.94/60
• 720p 25/ 29.97/ 30/ 50 / 59.94 / 60
• 1080i 50 / 59.94 / 60
• 1080p 25/ 29.97/ 30/ 50 / 59.94 / 60
• 2160p 25/ 29.97/ 30/ 50 / 59.94/60
• 720p 25/ 29.97/ 30/ 50 / 59.94 / 60
• 1080i 50 / 59.94 / 60
• 1080p 25/ 29.97/ 30/ 50 / 59.94 / 60
• 2160p 25/ 29.97/ 30/ 50 / 59.94/60
IP Transport Standard Support • SMPTE ST 2110 suite, including:
-10, System Timing and Definitions
-20, Uncompressed Active Video
-30, PCM Digital Audio
-40, ANC Data
• SMPTE ST 2110 suite, including:
-10, System Timing and Definitions
-20, Uncompressed Active Video
-30, PCM Digital Audio
-40, ANC Data
• SMPTE ST 2110 suite, including:
-10, System Timing and Definitions
-20, Uncompressed Active Video
-30, PCM Digital Audio
-40, ANC Data
• SMPTE ST 2110 suite, including:
-10, System Timing and Definitions
-20, Uncompressed Active Video
-30, PCM Digital Audio
-40, ANC Data
System Timing and Reference PTP Slave (SMPTE 2059, AES67 and IEEE-1588 default profiles) PTP Slave (SMPTE 2059, AES67 and IEEE-1588 default profiles) PTP Slave (SMPTE 2059, AES67 and IEEE-1588 default profiles) PTP Slave (SMPTE 2059, AES67 and IEEE-1588 default profiles)
Control and Setup • NMOS IS-04 and IS-05 for AIMS-compliant discovery,
registration and connection control
• EmBER+ discovery, registration and
connection control from popular 3rd-party control systems
• Provisioning and monitoring via DashBoard and/or our
published JSON API
• NMOS IS-04 and IS-05 for AIMS-compliant discovery,
registration and connection control
• EmBER+ discovery, registration and
connection control from popular 3rd-party control systems
• Provisioning and monitoring via DashBoard and/or our
published JSON API
• NMOS IS-04 and IS-05 for AIMS-compliant discovery,
registration and connection control
• EmBER+ discovery, registration and
connection control from popular 3rd-party control systems
• Provisioning and monitoring via DashBoard and/or our
published JSON API
• NMOS IS-04 and IS-05 for AIMS-compliant discovery,
registration and connection control
• EmBER+ discovery, registration and
connection control from popular 3rd-party control systems
• Provisioning and monitoring via DashBoard and/or our
published JSON API
