| STANDARD FEATURES |
|
| Solid-State programmable audio and video delay |
|
| Video Defocus Concealment |
|
| Audio Jumble Concealment |
|
| Non-Volatile User Setup Memories |
|
| Auto Bypass upon: Power Loss | Catastrophic Failure |
|
| HD Video Standards & Optional UHD-4K Video Standards |
|
| 16-Track Embedded Digital Audio on SDI I/Os |
|
| 16-Track AES Digital Audio I/Os on TASCAM DIGITAL D25 |
|
| GPI I/O for Control Panel & Tally |
|
| Hot-Swap Redundant Power Supplies |
|
| OPTIONAL FEATURES |
|
| AirCleaner Hardware Control Panel |
|
| UHD-4K 2160p Video Standards: Software License* |
|
| SUPPORTED VIDEO STANDARDS |
(All: HDR & WCG capable with 10-Bit Sources) |
| Via HD-SDI 1.5Gb/s |
| 720p50 | 720p59.94 |
| 1080psf23.98 |
| 1080p23.98 | 1080p24 | 1080p25 | 1080p29.97 | 1080p30 |
| 1080i50 | 1080i59.94 |
|
| Via HD-SDI 3Gb/s |
| 1080p50 | 1080p59.94 | 1080p60 | |
| Via UHD-SDI 12Gb/s (Optional) |
| 2160p50 | 2160p59.94 | 2160p60| |
| DIGITAL VIDEO INPUT [PGM IN] |
(QTY 1) Female HD-BNC
|
| HD 720p | HD 1080i |
HD-SDI: SMPTE 292M (1.5 Gb/s @ 10-Bits) |
| HD 1080p |
HD-SDI: SMPTE 424M (3.0 Gb/s @ 10-Bits) |
| UHD-4K 2160p (Optional) |
UHD-SDI: SMPTE 2082 (12.0 Gb/s @ 10-Bits) |
| DIGITAL VIDEO INPUT [AUX IN] |
(QTY 1) Female HD-BNC
|
| HD 720p | HD 1080i |
HD-SDI: SMPTE 292M (1.5 Gb/s @ 10-Bits) |
| HD 1080p |
HD-SDI: SMPTE 424M (3.0 Gb/s @ 10-Bits) |
| UHD-4K 2160p (Optional) |
UHD-SDI: SMPTE 2082 (12.0 Gb/s @ 10-Bits) |
| DIGITAL VIDEO OUTPUT [PGM OUT] |
(QTY 1) Female HD-BNC
|
| HD 720p | HD 1080i |
HD-SDI: SMPTE 292M (1.5 Gb/s @ 10-Bits) |
| HD 1080p |
HD-SDI: SMPTE 424M (3.0 Gb/s @ 10-Bits) |
| UHD-4K 2160p (Optional) |
UHD-SDI: SMPTE 2082 (12.0 Gb/s @ 10-Bits) |
| DIGITAL VIDEO OUTPUT [TAP OUT] |
(QTY 1) Female HD-BNC
|
| HD 720p | HD 1080i |
HD-SDI: SMPTE 292M (1.5 Gb/s @ 10-Bits) |
| HD 1080p |
HD-SDI: SMPTE 424M (3.0 Gb/s @ 10-Bits) |
| UHD-4K 2160p (Optional) |
UHD-SDI: SMPTE 2082 (12.0 Gb/s @ 10-Bits) |
| EMBEDDED DIGITAL AUDIO INPUT & OUTPUT |
(ALL) SDI INPUT & OUTPUT HD-BNCs
Accommodates AC-3 and Dolby-E Compressed Bit Streams |
| [ PGM IN | AUX IN | TAP OUT | PGM OUT ] |
HD-SDI & UHD-SDI = 16-Tracks |
| AES DIGITAL AUDIO INPUT & OUTPUT |
(QTY 1) Female 25D [TASCAM DIGITAL/AES-59 Cabling pin-out]
Accommodates AC-3 and Dolby-E Compressed Bit Streams |
| [ PGM IN | AUX IN | TAP OUT | PGM OUT ] |
AES/EBU 48kHz @ 24-Bits
8-Tracks (4 Stereo pairs) IN
8-Tracks (4 Stereo pairs) OUT |
| ANALOG AUDIO MONITORING OUTPUT |
(QTY 1) Female 3.5mm
Selectable to monitor any “stereo audio pair” from PGM OUT |
| Unbalanced Line Level @ –10 dBV |
2-Tracks (1 stereo pair) |
| ANALOG REFERENCE INPUT |
(QTY 2) Female HD-BNC |
| Tri-Level HD | Bi-Level Composite Analog SD |
Loop-Through |
| DATA / CONTROL |
|
| 100/T Ethernet |
(QTY 1) Female RJ45 |
| GPI I/O (Control Panel & Tally) |
(QTY 1) Female 9D |
| PHYSICAL & ELECTRICAL |
|
| 2RU Chassis – Dimensions |
W = 17.0 in | H = 3.00 in | D = 23.60 in
W = 43.18 cm | H = 8.90 cm | D = 60.00 cm |
| 2RU Chassis – Weight |
>27 lbs.
>12.25 kg. |
| Control Panel – Dimensions |
W = 6.35 in | H = 2.28 in | D = 3.78 in
W = 16.13 cm | H = 58.00 cm | D = 96.10 cm |
| Control Panel – Weight |
>3 lbs.
>1.36 kg. |
| 2RU Chassis AC Power Input |
100 to 240 VAC | 8 to 4 Amps | 47 to 63 Hz
(Input Power Auto-Sensing) |
| 2RU Chassis AC Power Consumption |
< 500W |
| SAFETY & EMISSIONS COMPLIANCE |
|
| IEC/EN 62368-1 |
|
| FCC PART 15 |
|
| ICES-003 |
|
| CE DIRECTIVE 93/68/EEC |
|
| CISPR 32:2015 | AMD1:2019 |
|
| MODEL |
Maximum Delay Time in Seconds for 59.94 video frame rate |
| 720p | 1080i |
1080p |
2160p |
| AirCleaner-2 Model-A |
80s |
40s |
10s |
| AirCleaner-2 Model-B |
160s |
80s |
20s |
| AirCleaner-2 Model-C |
360s |
180s |
45s |
* Optional 2160p UHD-4K Video Standards consists of a one-time license installed over the internet; or installed at time of initial purchase of AirCleaner-2.
